    976nm 140w High Power Fiber Coupled Laser Diode Detachable For Fiber Laser Pump Source

    Ask Lasest Price
    Brand Name : BWT
    Model Number : K976BN1RN-140.0W
    Certification : ISO9001
    Payment Terms : T/T
    Delivery Time : 4-8weeks
    • Product Details
    • Company Profile

    976nm 140w High Power Fiber Coupled Laser Diode Detachable For Fiber Laser Pump Source

    976nm 140w Fiber Detachable High Power Diode Laser For Fiber laser pump source


    Features:

    Wavelength: 976±1nm

    Output powe: 140W
    Fiber core diameter:106.5μm
    Optical fiber numerical aperture:0.22 NA
    Feedback protection:1020nm~1200nm


    Applications:

    Fiber laser pump source

    Specifications(25)

    Symbol

    Unit

    K976BN1RN-140.0W
    MinimumTypicalMaximum

    Optical Data(1)

    CW-Output PowerPoW140--
    Center Wavelengthλcnm976±1
    Spectral Width (FWHM)△λnm--1
    Wavelength Shift with Temperatureλ /△Tnm/℃-0.02-
    Wavelength Shift with Currentλ /△Anm/A-0.03-

    Electrical Data

    Electrical-to-Optical EfficiencyPE%-48-
    Operating CurrentIopA-1314
    Threshold CurrentIthA-0.9-
    Operating VoltageVopV-22.423.8
    Slope EfficiencyηW/A-11.6-

    Fiber Data

    Core diameterDcoreµm-106.5-
    Cladding DianmeterDcoreµm-125
    Numerical ApertureN.A.--0.22-
    Fiber Lengthlfm-2-
    Fiber Loose Tubing Dlameter-mm0.9
    Minimun Bending Radius-mm50--
    Fiber Termination--None
    Feedback lsolationwavelength Range-nm1020-1200
    lsolation-dB-30-

    Others

    ESDVesdV--500

    Storage Temperature(Non-

    operating)(2)


    Tst


    -20-70
    Lead Soldering TempTls--260
    Lead Soldering Timetsec--10
    Operating Case Temperature(3)Top20-30
    Relative HumidityRH%15-75

    (1) Data measured under operation output at 140W@25℃.

    (2) A non-condensing environment is required for operation and storage.

    (3) Operating temperature defined by the package housing. Acceptable operating range is 20 - 30℃, but performance may vary.
